Glossary of terms
Detection warning 2
Output signal (single channel) that describes the monitoring status of detection field 2.
Detection warning group 1
Output signal (single channel) that describes the monitoring status of the detection fields belonging to
group 1.
Detection warning group 2
Output signal (single channel) that describes the monitoring status of the detection fields belonging to
group 2.
F
Field of view
Sensor area of vision characterized by a specific angular coverage.
Fieldset
Structure of the field of view which can be composed of one or two detection fields.
FMCW
Frequency Modulated Continuous Wave
H
Horizontal angular coverage
Property of the field of view that corresponds to the coverage of 110° or 50° on the horizontal plane.
I
Inclination
Sensor rotation around the x-axis. The sensor inclination is the angle between a line perpendicular to the
sensor and a line parallel to the ground.
M
Machinery
The system for which the dangerous area is monitored.
Monitored area
Area that is monitored by Inxpect Value Line. It is composed of detection field 1 (e.g. used as alarm
area) and detection field 2 (e.g. used as warning area) of all the sensors.
O
OSSD
Output Signal Switching Device
