9.2.7 Event description

A complete description of the event is reported. Whenever possible, depending on the event, additional
parameters are reported.
In case of a diagnostic event, an internal error code is also added, useful for the purpose of debug. If the
diagnostic event disappears, the label "(Disappearing)" is reported as an additional parameter.
Examples
Detection access (field #3, 1300 mm/40°)
System configuration #15
CAN ERROR (Code: 0x0010)
CAN ERROR (Disappearing)

9.2.8 Log file example

Event logs of ISC NID UP304 updated 2020/11/18 16:59:56
[Section 1 - Event logs]
380 2020/11/18 16:53:49
375 2020/11/18 16:53:44
356 2020/11/18 16:53:25
30 2020/11/18 16:53:52
27 2020/11/18 16:47:56
5 2020/11/18 16:47:30
0 2020/11/18 16:47:25
92 Rel. 0 d 00:01:32
90 Rel. 0 d 00:01:30
70 Rel. 0 d 00:01:10
61 Rel. 0 d 00:01:01
0 0 d 00:00:00 [INFO]
[Section 2 - Diagnostic events log]
380 Rel. 0 d 00:06:20
375 Rel. 0 d 00:06:15
356 Rel. 0 d 00:05:56
30 Rel. 0 d 00:00:30
27 Rel. 0 d 00:00:27
5 Rel. 0 d 00:00:05

9.2.9 Event list

The event logs are listed below:
Event
Diagnostic errors
System Boot
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
COMMUNICATION LOST
[ERROR] SENSOR#1
[ERROR] SENSOR#1
[INFO] CONTROL UNIT
[ERROR] SENSOR#1
[ERROR] SENSOR#1
[ERROR] SENSOR#1
[INFO] CONTROL UNIT
[INFO] CONTROL UNIT
[INFO] CONTROL UNIT
[INFO] SENSOR#1
[INFO] SENSOR#1
CONTROL UNIT System Boot #61
[ERROR] SENSOR #1
[ERROR] SENSOR #1
[INFO] CONTROL UNIT
[ERROR] SENSOR #1
[ERROR] SENSOR #1
[ERROR] SENSOR #1
Type
ERROR
INFO
CAN ERROR (Disappearing)
CAN ERROR (Code: 0x0010)
System configuration #16
ACCELEROMETER ERROR (Disappearing)
ACCELEROMETER ERROR (Code: 0x0010)
SIGNAL ERROR (Code: 0x0012)
System Boot #60
Detection exit (field #2)
Detection exit (field #1)
Detection access (field #2, 3100 mm/20°)
Detection access (field #1, 1200 mm/30°)
CAN ERROR (Disappearing)
CAN ERROR (Code: 0x0010)
System configuration #16
ACCELEROMETER ERROR
ACCELEROMETER ERROR (Code: 0x0012)
SIGNAL ERROR (Code: 0x0014)
COMMUNICATION LOST
TILT ANGLE ERROR
MASKING
COMMUNICATION LOST
(Disappearing)
TILT ANGLE ERROR
MASKING
9. Troubleshooting
