9. Troubleshooting

Contents
This section includes the following topics:

9.1 Troubleshooting procedures

9.2 Event log management
9.3 INFO events
9.4 ERROR events (control unit)
9.5 ERROR events (sensor)
9.6 ERROR events (CAN bus)
9.1 Troubleshooting procedures
Note: if requested by Technical Support, in Settings > Activity History, click Download sensor debug info to
download the files and forward them to Inxpect for debugging.
9.1.1 Control unit LED
For more details about the LEDs in the control unit, see "Control units" on page 13 and "System status LEDs" on
page 14.
LED Status
S1* Steady red
S2 Steady red
S3 Steady red
S4 Steady red
Inxpect Value Line | Instruction manual v1.0 FEB 2025| Inxpect VL-IM-7_00375_en_v1.0 | © 2025 Inxpect SpA
Application messages
CONTROL UNIT
POWER ERROR
CONTROL UNIT
TEMPERATURE ERROR
OSSD ERROR or INPUT
ERROR
PERIPHERAL ERROR
Problem
At least one voltage If at least one digital input is
value on the control connected, check that the
unit is wrong SNS input and the GND input
are connected.
Check that the input power
supply is the specified type
(see "General specifications"
on page 79).
Control unit Check that the system is
temperature value operating at the correct
is wrong operating temperature (see
"General specifications" on
page 79).
At least one input or If at least one input is used,
output is in error check that both the channels
are connected and that there
is no short-circuit on the
outputs.
If the problem persists,
please contact Technical
Support.
At least one of the Check the status of the
control unit terminal block and
peripherals is in connections.
error
If the problem persists,
please contact Technical
Support.
65
67
71
73
74
75
Solution
65
