8. Installation and use procedures
3. Start the Inxpect Safety application.
4. Choose the connection mode (USB).
5. Set a new admin password, memorize it, and provide it only to authorized people.
6. Set the number of sensors.
7. Select the system Inxpect Value Line and the number of sensors.
8.3.3 Define the area to be monitored
WARNING! The system is disabled during configuration. Prepare opportune measures in the
dangerous area protected by the system before configuring the system.
1. In the Inxpect Safety application click Configuration.
2. Optional. Add the desired number of sensors in the plane.
3. Define the position and inclination of each sensor.
4. Define the detection distance and, only for S188A-X3 sensors, the restart timeout for each detection field of
each sensor.
8.3.4 Configure the inputs and outputs
1. In the Inxpect Safety application, click Settings.
2. Click Digital Input-Output and define the input and output functions.
3. If the muting is managed, click Settings > Muting and assign the sensors to the groups according to the logic
of the digital inputs.
4. If needed, in Settings > Restart function and choose the type of managed restart.
5. Click APPLY CHANGES to save the configuration.
8.3.5 Save and print the configuration
1. In the application, click APPLY CHANGES: the sensors will save the inclination set and the surrounding
environment. The application will transfer the configuration to the control unit, and once transfer is complete
it will generate a configuration report.
2. Click to save and print the report.
Note: to save the PDF, a printer must be installed on the computer.
3. Ask the authorized person for a signature.
8.3.6 Assign the Node IDs
Type of assignment
Note: if the connected sensors do not already have a Node ID assigned (e.g., at first startup), the system
automatically assigns them a Node ID during the installation procedure.
Three types of assignment are possible:
Manual: to assign the Node ID to a sensor at a time. Can be performed with all the sensors already
l
connected or after each connection. Useful for adding a sensor or to change Node ID to a sensor.
Automatic: to assign the Node IDs to all the sensors at once. To be performed when all the sensors are
l
connected.
Note: the control unit assigns the Node ID in ascending order of sensor ID (SID).
Semi-automatic: wizard for connecting the sensors and assign the Node ID one sensor at a time.
l
Procedure
1. Start the application.
2. Click Configuration and verify that the number of sensors in the configuration is the same as those
installed.
