3.4
G16 International Power Strip
The G16 International Power Strip allows connection of standard corded products from
several different countries. These being:
Switzerland
Italy
Continental Europe
United States
Denmark
United Kingdom
Australia
Refer to Figure 3-4 for connection of the G16 International Power Strip to the Guardian 5000.
www.valuetronics.com
HIGH-VOLTAGE
UNKNOWN
HIGH
LOW
SENSE
WV
DRIVER
Green
Green/Yellow
(Chassis ground, can also be connected to chassis
ground connector of Guardian 5000 rear panel)
G16 International Power Strip Connection
White
Black
G16 International Power Strip
Figure 3-4
Maintenance & Calibration 3-19
