QuadTech Guardian 5000 Instruction Manual page 21

HIGH-VOLTAGE
HIGH
www.valuetronics.com
UNKNOWN
LOW
Alligator Clip Lead
SENSE WV
DRIVER Large Alligator Clip Lead
Large Alligator Clip Lead
(Red)
Connect to Case
of DUT
Connection for Hipot and Ground Continuity Test
(Using S02 (HV cable) and G15 Clip Lead Sets)
HIGH-VOLTAGE
UNKNOWN
HIGH LOW
SENSE
DRIVER
Large Alligator Clip Lead
Connection for Hipot and Ground Continuity Test
(Using G15 (one cable) & G14 Power Entry Cable)
Shorted
Together
(Red)
(Black)
Device Under
Test
Figure 2-4
Red Lead
Black Lead With
Retaining Bracket
WV
Black Lead
With Lug
(Red)
Connect to Case
of DUT
Figure 2-5
Connect to Power Ground
of DUT
(DUT)
Device Under
Test (DUT)
Operation 2-5
