Programming Insulation Resistance (Ir) Test - QuadTech Guardian 5000 Instruction Manual

To store the present set of test conditions proceed as follows:
•
If the instrument is in programming mode (any lights blinking) press the PROG key.
•
Press the STO key.
•
From the Data Entry Keys type the setup number desired (1 - 50).
•
Press ENTER to store the present test conditions.
2.7

Programming Insulation Resistance (IR) Test

Test Step
STEP
2
OFF ON
With the instrument in standby status (Stop button previously pressed and no lights blinking)
press the arrow UP
programmed. If the desired selection is an IR test proceed as described below, if selection is a
Hipot test refer to paragraph 2.6, if selection is ground continuity refer to paragraph 2.8.
Press PROG key and ENTER to begin the parameter change. The test mode indicator will
blink, arrow UP
Operation 2-12
www.valuetronics.com
Test Voltage
R
750
W-ACV
AC
W-DCV
DC
I-R
RMT LOCK
7
STOP START
4
1
0
or arrow DOWN
or arrow DOWN
Resistance
A
HI
2.00
KV
LO
V ARC
OFFSET HI-NG LO-NG ARC-NG
8 9 PROG RCL
5 6 DELE STO
CLEAR OFFSET
2 3
.
OFF ENTER
to select the test step # (1 - 15) to be
to select I-R and press ENTER.
Time
TIMER
m
SEC
5.0
uA mA
TEST
M G RAMP
PASS
CURSOR
