St - 3 (Ground Continuity test frequency)
The current frequency is shown on the Timer display. From the Data Entry Keys type the
frequency desired [50 or 60] and ENTER.
St - 4 (IR test delay time)
The current delay time is shown on the Timer display. From the Data Entry Keys type the
time desired [.3 - 999] and ENTER.
St - 5 (Pass indicator hold time)
The current Pass indicator hold time (time in which the Pass indicator remains on after test is
complete) is shown on the Timer display. From the Data Entry Keys type the time desired [.2
- 99.9] and ENTER.
St -6 (step delay)
The current delay time (delay time between steps) is shown on the Timer display. From the
Data Entry Keys type the time desired [.1 - 99.9] and ENTER.
St - 7 (Ground Continuity voltage)
The current ground continuity test voltage is shown on the Timer display. From the Data
Entry Keys type the test voltage desired [6.0 - 15.0] and ENTER.
St - 8 (Hipot automatic gain control)
The current AGC setting (on or off) is shown on the Timer display. From the Data Entry Keys
press the OFF key to toggle the on/off.
St - 9 (Buzzer)
The current Buzzer setting (off or audible levels of 1, 2, or 3) is shown on the Timer display.
From the Data Entry Keys press the OFF or 1, 2, or 3 key and ENTER to turn off or on. 1 is
low volume, 2 is mid-range volume and 3 is high volume.
St - A (Pass indicator hold)
The current Pass indicator hold, on or off (with selection of on Pass indicator remains on until
the next test is initiated) is shown on the Timer display. From the Data Entry Keys press the
OFF key to toggle the on/off.
St - b (# of scanner)
The current # of scanner selected (1 - 8) is shown on the Timer display. From the Data Entry
Keys type the number of scanners to be connected [1 - 8] and ENTER.
St - C (Continue on fail)
The current setting for continue on fail (on or off) is shown on the Timer display. From the
Data Entry Keys press the OFF key to toggle the on/off.
Operation 2-17
