QuadTech Guardian 5000 Instruction Manual page 13

Fig 1-2
Ref. # Item
22 CURSOR
keys
23 Data Entry
Keys
24 START
button
25 STOP
button
26 OFF/ON
www.valuetronics.com
Table 1-1
Front Panel Controls and Indicators (continued)
Function
Under STOP status:
or DOWN to examine 1 - 15 steps
UP
Under Hipot test On:
or DOWN to increase or decrease test voltage in
UP
continuous mode
Under PROG status:
LEFT or RIGHT
or DOWN to change status status
UP
[0] [.] .....[9] Numerical keys to input test parameters
For turning off test parameters (limits, arc, etc.)
[OFF]
[PROG] To enter and exit parameter setting status
To delete a test step, those below move up
[DELE]
To cancel parameter number and input again
[CLEAR]
Press to confirm enter parameter
[ENTER]
Recalls stored parameters (1 - 50) from memory
[RCL]
[STO] Stores parameter (1 - 50) into memory
Initiates zeroing offset function
[OFFSET]
Pressing this button starts a test and applies high voltage/current
to the test terminals.
Pressing this button stops a test in process and must be pressed
as a reset function before a test can be started (after a failed test
or after test conditions have been reprogrammed).
Applies AC power to the tester, 0 is off, 1 is on.
to select parameter for programming
Introduction 1-5
