3.2.2.1 Listener Functions

Item Command
1 STOP
2 TEST
3 SHOW (?)
4 STEP (?)
5 MODE (?)
6 SOUR (?)
7 VOLT (?)
8 CURR (?)
9 HILI (?)
10 LOLI (?)
11 SARC (?)
12 HICH (?)
13 LOCH (?)
14 TIME (?)
15 RAMP (?)
16 *SAV
17 *RCL
18 CLER
19 *IDN (?)
20 *DDT (?)
21 *TRG
22 *RST
where x: no parameter required
www.valuetronics.com
Parameter
X
X
{c}
{n}
{n | c}
{f}
{f}
{f}
{f | *}
{f | *}
{f | *}
{n | *}
{n | *}
{f | *}
{f | *}
{n}
{n}
X
X
{n | c}
X
X
n: indicates integer
f: indicates floating
c: indicates memory mark
*: indicates the "*" character of ASCII
Function
stop test
start test
set testing value
set Step
set test mode
set output voltage or current
set output voltage
set output current
set High Limit
set Low Limit
set ARC
set High Channel
set Low Channel
set the test time
set the voltage rise time
save the setting value
read the setting value
clear the memory
check the unit number
set the response to Trigger
execute Trigger command
reset the unit
Maintenance & Calibration 3-5
