3.3

Scanner Interface

3.3.1 Scanner Accessories

Item
G17, 25 pin interconnect cable (Guardian 5000 to Scanner)
Test Lead Set, Hipot (Guardian Output to Scanner I/P)
G21, Scan Clip Leads, Hipot (Scanner front panel outputs to DUT)
Sheathed banana (orange) to alligator clip (red)
*G20, Interconnect Cable, GC (Guardian Output to Scanner rear
panel GC Input) Banana plug/lug, (red/black) to banana plug/lug
(red/black)
*G15, Scan Clip Lead Set, GC (Scanner rear panel GC outputs to DUT)
Large alligator clips (red/black) to banana plug/lug (red/black)
Scan Card for Guardian 5000

3.3.2 Scanner Card Installation

The 5000-01 and 5000-02 Scanners are supplied with an interface card that must be installed
in the Guardian 5000. Proceed as follows:
•
Remove the three screws which secure the Guardian 5000 top cover to the rear panel. The
top cover is removed by lifting up and back, out of the front panel groove.
•
Remove the 2 screws (to the right of the rear panel SCAN connector hole) and remove the
filler panel.
Maintenance & Calibration 3-14
www.valuetronics.com
Guardian 5000 Scanner Accessories
G18, HV plug to sheathed banana plug (red)
G19, Banana plug(w/retaining bracket) to sheathed banana
plug (black)
* Only included with 5000-02 (GC scanner)
Table 3-1
Quantity
1
1
1
8
1
4
1
