QuadTech Guardian 5000 Instruction Manual page 27

Arc
From the Data Entry Keys type the desired arc current limit and then press ENTER.
to 40.00mA AC, or 20.00mA DC is the allowable range). Any measured value of arc current
above this will result in a fail decision. An entry of 0 disables the limit detection.
Test Time
From the Data Entry Keys type the desired test time and then press ENTER. (0.1 to 999s is
the allowable range). A test time of 0 sets the instrument to continuous test mode.
EXTREME CAUTION MUST BE USED BY THE OPERATOR, IN CONTINUOUS
MODE, HIGH VOLTAGE IS APPLIED TO THE TEST TERMINALS UNTIL THE
STOP BUTTON IS DEPRESSED OR A LEAKAGE CURRENT BREAKDOWN
Ramp Time
From the Data Entry Keys type the desired ramp time and then press ENTER. (0.1 to 99.9s
is the allowable range). A test time of 0 for a display of [ - - - - ] sets the ramp time to zero.
After the final test condition entry (ramp time) the instrument returns to the blinking test step
#. Press PROG key to return to standby status in preparation for testing.
If test conditions are to be changed in another step, arrow UP
select the other step:
•
if a hipot test, set the test conditions as described in this paragraph.
•
if a insulation resistance test refer to paragraph 2.7 for setting test conditions.
•
if a ground continuity test refer to paragraph 2.8 for setting test conditions.
www.valuetronics.com
WARNING
OCCURS.
OR
(0.500
or arrow DOWN to
Operation 2-11
