3.2.2.2 Talker Functions

The message of {string + ending code} will be sent when the instrument is assigned as
TALKER. The ending code consists of CR+LF+EOI. The string is dependent on the present
status.
There are several commands with the "?". These commands send the testing value by ASCII
string.
Example:
All commands will feed back an error message except *RST, *TRG , show and "?'. If the
error code is not 0 the result will be displayed. Error messages are as follows:
Error Messages
Error 0: Save OK!
Error 1: The command is not valid
Error 2: The parameters are not valid
Error 3: Can not start test
Error 4: Scanner is not connected
Error 5: Channel can not set 0
Error 6: Channel invalid
The TALKER function is completed by SHOW(?) command. The instrument will send back
the testing value for the parameter selected. It may check more than one test value by
connecting the parameters with "|".
Status Messages
Status 0: Presently in STOP status
Status 1: Presently in TEST status
Status 2: Test complete, condition is PASS
Status 3: Test stop, condition is FAIL
Status 4: Test stop, Hipot arc limit FAIL
Status 5: Test stop, Hipot high limit FAIL
Status 6: Test stop, Hipot low limit FAIL
Status 7: Test stop, IR high limit FAIL
Status 8: Test stop, IR low limit FAIL
Status 9: Test stop, GC high limit FAIL
www.valuetronics.com
1. Command : mode WD: mode?
: MODE 2 : With Standing DC voltage test mode.
2. Command : high 1|3|5; high?
:HICH 1|3|5 ; High Channel 1,3,5 is ON
