To change a test mode select the step to be changed (1 to 15) as described above and press
PROG and then ENTER (the VAC/VDC /IR/RΩ light will be blinking).
•
Arrow UP
press ENTER again.
•
Once the desired test mode has been selected refer to paragraph 2.6 for changes to Hipot
test conditions and paragraph 2.7 for changes to IR test conditions and paragraph 2.8 for
changes to Ground Continuity test conditions.
Example of test mode change (step 1 an AC Hipot and step 2 an IR test):
•
In standby mode (with no light blinking), arrow UP
Step 1. Press PROG and then ENTER. UP
for this step and then ENTER.
Starting with test voltage enter the test conditions for step 1 as discussed in paragraph 2.6
for Hipot test conditions. Return to standby mode (with no light blinking) by pressing
PROG key
•
In standby mode (with no light blinking), arrow UP
Step 2. Press PROG and then ENTER. UP
step and then ENTER.
Starting with test voltage enter the test conditions for step 2 as discussed in paragraph 2.7
for IR test conditions. Return to standby mode (with no light blinking) by pressing
PROG key
www.valuetronics.com
or DOWN to the newly desired test mode (VAC/VDC/IR/RΩ) and
or arrow DOWN
or arrow DOWN
or arrow DOWN
or arrow DOWN to select I-R for this
to select
to select W-ACV
to select
Operation 2-9
