QuadTech Guardian 5000 Instruction Manual page 11

Fig 1-2
Ref. # Item
1 Step
2 Mode
RΩ/W-ACV DC Hipot or Insulation Resistance mode status.
W-DCV/IR
3 RMT
Indicator
4 Voltage or
Current
Display
5 LOCK
Indicator
6 Display Units Indicates the units for the current/voltage display (AC or DC, A,
7 OFFSET
Indicator
8 Limit
Indicator
9 Limit/Measure Display shows limit setting when test is not in process and
10 Result
Indicators
www.valuetronics.com
Table 1-1
Front Panel Controls and Indicators
Function
Display indicates step number selected in the auto test sequence
(1 to 15). Indicates memory group number (1 to 50) when RCL
(recall) or STO (store) is selected.
Light indicates that tester is in Ground Continuity, AC Hipot,
Light indicates when instrument is in remote mode.
Display shows voltage/voltage setting value when test is not in
process and shows output voltage/current when test is in process.
0.1 - 5KV for AC Hipot, 0.5 - 6KV for DC Hipot,
100 - 1000V for IR, and 1.0 - 30.0A for GC,
Light indicates when instrument front panel keys are locked
KV for hipot, V for IR or A for GC)
Light indicates when instrument offset function is enabled.
Indicates the function of the limit shown on the Limit Display
(HI, LO, or ARC)
shows measured value when test is in process.
Lights indicate test results based on set limits.
Measured value exceeded high limit
HI NG -
Measured value less than low limit
LO NG -
ARC NG - Measured value exceeded arc limit
Measured value is good based on all set limits
PASS -
Introduction 1-3
