Front Panel Description

Figure 1-2 shows the controls and indicators on the front panel of the Guardian 5000. Table
1-1 identifies them with descriptions and functions.
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
26 25 24 23 22 21 20 19 18 17
Figure 1-2
Front Panel Controls & Indicators
Introduction 1-2
