Mirror Name Mirror Location
In the back left of the
1st Mirror machine beyond the
far end of the Y axis
On the Y axis at the
2nd Mirror
left end of the X axis
On top of the laser
3rd Mirror
head on the X axis
Cleaning Method
Clean with lens-cleaning tissue or with cotton wetted
with lens-cleaning liquid or isopropyl alcohol in gentle
circular motions.
T h e 3 p o s i t i o n i n g m i r r o r s c a n b e c l e a n e d i n
place or removed for cleaning by turning them
counterclockwise.
If any mirrors are removed for cleaning, reinstall them
by turning them into place clockwise carefully.
