4 Operation
2. Place your rotary axis in an open area.
3. Put the material and adjust the position using the rotary axis' knobs.
4. Check the height of the workbed is appropriate. If necessary, lower the workbed to provide
room for the laser head to pass over your axis and material.
5. Connect the rotary axis cord to the rotary port at the back of the main bay.
4.5.2 Engraving Procedures with a Rotary Attachment
In typical workflows, designs are created by using graphic files on a control computer, and then
transferred to the engraver for execution. Here are the main operation steps:
Start
Check and power on
Prepare your material
Prepare your design file
and set parameters
Focus
Set Distance per Pulse and
other rotation parameters
Engrave
Adjust parameters
No
Is the result ok?
Yes
Power off
End
