3 Installation
3.1 Installation Overview
A complete working system consists of the following parts:
• A laser engraving cabinet
The cabinet can use designs provided by the enclosed engraving software by direct or internet
connection with your computer; it can also engrave designs loaded directly from a flash drive.
• A water cooling system
• A ventilation system adequate for the materials you're working with (fan and ducts included)
• All applicable connection cables
• Laser and door keys
Use only the hardware, wiring, and power sources that came with or are
compatible with this engraver. Installing equipment that your engraver is not
designed to work with can lead to poor performance, shortened service time,
increased maintenance costs, property damage, and personal injury.
Users can configure other accessories (such as a fume extractor or rotary axis) to suit their needs.
Note the specific requirements of your system's installation. Every customer must understand these
notes before installation to execute a proper setup and achieve safe laser performance. If you have
any installation questions or problems, contact our technicians and customer support team.
Any auxiliary equipment must be adjusted to the base machine. Queries may be directed to the
dealer or manufacturer of such equipment.
3.2 Selecting a Location
The location should meet all of the following requirements:
• The location meets all of the requirements mentioned in
• The location should be stable, level, dry, and climate-controlled to ensure an ambient
temperature of 40 ℉ –95 ℉ and an ambient humidity under 70%. In particular, the temperature
and humidity together should not be close to the dew point.
• The location should be free of dust and other airborne pollutants and well-ventilated enough to
process any fumes produced by the engraving process in accordance with all applicable laws
and regulations.
§ 1 Safety Information
25
on Page 1.
