F Ground
Air Assist Pump Port
G
H Air Assist Intake
I Chiller Alarm Cable Port
J Water Inlet
K Water Outlet
This port connects to the dedicated grounding cable for safety
if applicable.
If additional air assist is needed, remove the cover and connect
your additional air assist through this port.
This intake provides the pressurized air for the machine's
air assist. Periodically check its filter to keep it clear of any
obstruction.
This port connects to the water chiller alarm cable.
This port connects to the outlet of a water cooling system.
This port connects to the inlet of a water cooling system.
