To manually access the suppressed event screens in
this condition, use the View lists option on the main
screen.

Warning status

You can program the control panel to provide
warning or delay-to-alarm status before alarm
status.
The warning display indicates a warning status, see
Figure 5.
Figure 5: Warning status screen
Callout Description
1 First warning
2 Warnings number
3 Control panel status
4 If flashing, the control panel is working
normally
5 The arrow symbols pointing right
indicate that there is more information
to view by using the Right key.
6 The arrow symbols pointing left indicate
that there is more information to view
by using the Left key.
7 Number of the displayed warning
8 Last warning
Note: If the events are linked to the devices,
the zone label alternates with the point label
every three seconds. If you have not assigned
the point to a zone, the screen shows the point
label only.
The panel generates a warning when a detector
exceeds its warning threshold and there is risk of an
alarm.
The following items signal the warning status:
• Warning output points
• Control panel display
• Intermittent audible signal on the panel buzzer
10 FC501 Addressable Fire Control Panels User Manual
• The repeaters
Figure 6 shows how to scroll the warning status
screens.
Figure 6: Scrolling warning status screens
Callout Descriptions
1 To scroll the second block of data for
the warning zones, press the Right key.
2 To scroll the third block of data for the
warning causes, press the Right key.
3 To scroll the fourth block of data for the
warning times, press the Right key.
Table 9: Keys function on the warning status
screens
Key Function
1 Displays the zones status screen
2 Displays the status screen of the first
point in warning status
3 Displays the status screen of the last
point in warning status
4 Displays further points in warning
status. When point information is
present in the fourth row, press the 4
key to display the status screen of the
related device.
Up Shows the next event. The display does
not show the next event if it is last.
