Statistics

This screen displays statistical information for any port or the
entire switch, depending on the display mode chosen. (See
Item 1 below)
Time Since Last Reset Switch Statistics :
No of Reset Switch Statistics Since Power On: 0
Local Frame Received
Forwarded Frames
Learning Broadcast Frames
Long Frames
Short Frames
Collisions
Return
Selecting one of ports or the switch
Displaying all statistics counters for selected port or whole switch
Press <CTRL><X> to cancel.
Figure 4-11. Statistics Screen
This screen provides the following options:
1. Highlight "Display" and press <ENTER> to select statistical
display. Use arrow keys to cycle through display selections
(Ports 1-8 or the whole switch). Press <ENTER> to confirm
the choice.
2. Highlight "Refresh Screen" and press <ENTER> to update
all statistics counters.
3. Highlight "Reset Statistics" and press <ENTER> to clear all
statistics counters.
See the chart on the following page for a description of the
statistics displayed on this screen.
