SMC Networks 6608M INT User Manual page 71

CONFIGURATION AND MANAGEMENT
LEDs
Power
RPU
Status
LED
Array
Forward %
Utilization % Indicates that the LED array is displaying the
Collision %
Full/Half
Diagnostic
4-20
Status LEDs
Functions
Indicates that the switch is receiving power.
Indicates that the optional Redundant Power
Unit is supplying power to the switch.
Indicates that the LED array is displaying status
information for each port (This is the default
display mode).
Tx/Rx (60%)
100Mbps (30%)
Full-Duplex (10%) Indicates that the port is set
Select/Link (1%)
Indicates that the LED array is displaying the
percentage of all packets forwarded by each
port to another port.
percentage of LAN bandwidth being utilized
by each port.
Indicates that the LED array is displaying the
percentage of packets in collision relative to the
total number packets transmitted by each port.
Indicates that the transmission mode for each
port may be manually set to full- or half-duplex.
Indicates that the unit is running internal
diagnostic tests.
Indicates that the port is
transmitting or receiving
data. (Blinking)
Indicates that the port is set
to operate at 100 Mbps.
(Unlit = 10 Mbps)
to operate in full-duplex
mode. (Unlit = half-duplex)
Indicates a valid network
connection.
