Trap Receivers Screen - SMC Networks 6608M INT User Manual

M
ANAGEMENT VIA
5. Highlight "Trap Receivers" in the SNMP Configuration
screen (Figure 5-1) and press <ENTER> to access the Trap
Receivers screen (Figure 5-3).
Index
1 10.148.72.66
Add Entry
Use cursor keys to choose item.
Press <CTRL><N> to return to the Main Menu.
Figure 5-3. Trap Receivers Screen
6. Highlight "Add Entry" and press <ENTER> to input an
IP Address for a receiver station and assign a community
name and index for that station. Repeat this step for each
receiver station required (up to 8).
5-6
SNMP
Trap Receivers
IP Address
Delete Entry
Community Names
SMC
Change Entry
Press <ENTER> to confirm choice.
Clear Entry
