Advanced System Monitoring

These following display screens can be accessed through the
System Configuration Program Main Menu under the
Information and Statistics section. The following section
headings reflect the items available in this area of the Main
Menu.

System Information

This screen displays descriptive information about the switch.
System Description
Interface Description
System Name
System Location
System Contact
System Up Time
No of Reset Since Power On
Return to Previous Menu
Use cursor keys to choose item.
Press <CTRL><N> to return to the Main Menu
Figure 4-9. System Information Screen
Parameter
System Description
Interface Description
System Name
System Location
System Contact
System Up Time
No of Reset Since
Power On
System Information
System Information Screen Items
System's model and name
ANSI/IEEE standards compliance
Name assigned to the switch
Specifies the location where switch resides
Contact person responsible for the system
Length of time the switch management
agent has been running
Number of times the switch has been reset
or the address table cleared
CONFIGURATION AND MANAGEMENT
SMC TigerSwitch 100
Ethernet 802.3/802.3u
SMC TigerSwitch 100
MIS
SMC Technical Support Dept.
19Day, 2HR, 41Min, 5Sec
2
Press <ENTER> to confirm choice.
Description
