TigerStack II 10/100
12- and 24-Port 10/100 Mbps Hubs
Forms a stack with up to 144 ports
K
Manageable via SNMP and RMON
K
10/100BASE-TX and 100BASE-FX extension modules
K
Support for redundant power unit
K

User Guide

SMC5912DS
SMC5924DS
SMC5912
SMC5924

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TigerStack II 10/100 and is the answer not in the manual?

Questions and answers

Summary of Contents for SMC Networks TigerStack II 10/100

  • Page 1: User Guide

    TigerStack II 10/100 12- and 24-Port 10/100 Mbps Hubs Forms a stack with up to 144 ports Manageable via SNMP and RMON 10/100BASE-TX and 100BASE-FX extension modules Support for redundant power unit User Guide SMC5912DS SMC5924DS SMC5912 SMC5924...
  • Page 2 TigerStack II 10/100 User Guide From SMC’s Tiger line of feature-rich workgroup LAN solutions 6 Hughes Irvine, CA 92618 May 1999 Phone: (949) 707-2400 Pub. # 150914-101 R02...
  • Page 3 Irvine, CA 92618 All rights reserved. Printed in Taiwan Trademarks: SMC is a registered trademark; and EZ Switch, TigerStack and TigerSwitch are trademarks of SMC Networks, Inc. Other product and company names are trademarks or registered trade- marks of their respective holders.
  • Page 4: Limited Warranty

    SMC or its Authorized Reseller: TigerStack II 10/100 Hubs ......Three Years...
  • Page 5 This warranty gives you specific legal rights which may vary from state to state. Nothing in this warranty shall be taken to affect your statutory rights. SMC Networks, Inc. 6 Hughes Irvine, CA 92618...
  • Page 6: Table Of Contents

    ABLE OF ONTENTS Compliances ............... v About the Hubs ..........1-1 Overview ................. 1-2 How to Use this Guide ............1-5 Twisted-Pair Ports ..............1-5 Status LEDs ................1-6 Switch Module ................. 1-7 Optional Network Management Module ......... 1-8 Optional Extender Modules ............. 1-9 Stacking Connectors ..............
  • Page 7 12-Port TigerStack II 10/100 Hubs .......... C-2 24-Port TigerStack II 10/100 Hubs .......... C-2 All TigerStack II 10/100 Hubs ..........C-3 Slide-In Modules ..............C-5 Ordering Information ........D-1 TigerStack II 10/100 Products and Accessories ...... D-2 Glossary ............E-1 Glossary of Terms ..............E-2...
  • Page 8 ABLE OF ONTENTS List of Figures Figure 1-1. Front and Rear Panels of the SMC5924DS and SMC5924 ............... 1-2 Figure 1-2. Stacking Base Hubs and Expansion Hubs .... 1-3 Figure 1-3. Twisted-Pair Ports ..........1-5 Figure 1-4. Port and Hub Status LEDs ........1-6 Figure 1-5.
  • Page 9 ABLE OF ONTENTS...
  • Page 10: Compliances

    OMPLIANCES FCC - Class A This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 11 OMPLIANCES 5. Das Gerät ist vor Feuchtigkeit zu schützen. 6. Bei der Aufstellung des Gerätes ist auf sicheren Stand zu achten. Ein Kippen oder Fallen könnte Beschädigungen hervorrufen. 7. Die Belüftungsöffnungen dienen der Luftzirkulation, die das Gerät vor Überhitzung schützt. Sorgen Sie dafür, daß diese Öffnungen nicht abgedeckt werden.
  • Page 12: About The Hubs

    HAPTER BOUT THE Overview ......1-2 How to Use this Guide ....1-5 Twisted-Pair Ports .
  • Page 13: Overview

    LAN extensions to create a flexible and fault-tolerant environment for Fast Ethernet integration and growth. TigerStack II 10/100 hubs are available in four different models. Each has either 12 or 24 10BASE-T/100BASE-TX ports plus two front-panel slots for slide-in modules: - SMC5912DS—12-port Base Hub preconfigured with Internal...
  • Page 14: Figure 1-2. Stacking Base Hubs And Expansion Hubs

    BOUT THE The DS model Base Hubs are preconfigured with an Internal Switch Module, and the Network Management Module can be added as an option. Expansion Hubs come without any preconfigured modules and can accept a variety of optional Extender Modules. The Extender Modules provide a switched link connection to the hub stack using either one 10BASE-T/ 100BASE-TX port, one 100BASE-FX port, or one 10BASE2 BNC or AUI connector.
  • Page 15 BOUT THE The hubs contain a comprehensive array of LEDs for “at-a-glance” monitoring of network and port status. Also, if the Base Hub contains a Network Management Module, the entire stack can be managed in-band via SNMP, RMON (groups 1, 2, 3 and 9), or a Web browser, as well as remotely via Telnet or SLIP.
  • Page 16: How To Use This Guide

    BOUT THE How to Use this Guide Please read Chapters 1 through 4 when installing the TigerStack II 10/100 hubs. If you have added a Network Management Module to one of the hubs as an option, also read the Advanced Reference Guide (included with this module) to learn how to manage your network.
  • Page 17: Status Leds

    BOUT THE Status LEDs The hub status LEDs are shown below and described in the following table. Figure 1-4. Port and Hub Status LEDs e l l ' e l v i t e l l v i t v i t y t i c i f s i l...
  • Page 18: Figure 1-5. Internal Switch Module

    BOUT THE Internal Switch Module Figure 1-5. Internal Switch Module Located in the top expansion slot of the DS hub models, the Internal Switch Module interconnects the 10 Mbps and 100 Mbps segments and employs a buffered store-and-forward architecture to prevent bad packets from being propagated throughout the network.
  • Page 19: Optional Network Management Module

    BOUT THE Optional Network Management Module Figure 1-6. Network Management Module As an option, a Network Management Module can be inserted into the bottom slot of any hub model to manage the entire stack. It offers a variety of management options, including SNMP, RMON and a web-based interface.
  • Page 20: Optional Extender Modules

    BOUT THE Optional Extender Modules Figure 1-7. Optional Extender Modules There are seven Extender Modules to choose from. Each provides a switched link from the stack’s 100 Mbps segment that can be used to extend the size and reach of the stack. The Extender Switch Modules also include the internal switch function to interconnect the 10 Mbps and 100 Mbps segments.
  • Page 21 BOUT THE - SMC5900T—one external 10BASE-T/100BASE-TX port, choice of crossover or daisy-chain connection - SMC5900FSC—one external 100BASE-FX port with SC connectors - SMC5900FST—one external 100BASE-FX port with ST connectors - SMC5900T/SW—one external 10BASE-T/100BASE-TX port, choice of crossover or daisy-chain connection; plus internal switch function - SMC5900FSC/SW—one external 100BASE-FX port with SC connectors;...
  • Page 22 BOUT THE The BNC and AUI ports allow connection to legacy 10 Mbps network segments. The BNC port connects to 10BASE2 thin coax. The AUI port can be connected to 10BASE5 thick coax or 10 Mbps fiber via an appropriate transceiver. The active port is selected by the toggle switch on the front of the module.
  • Page 23: Stacking Connectors

    BOUT THE Stacking Connectors The stacking connectors are located on the rear panel of each hub. Figure 1-8. Stacking Connectors One connector is labeled “Out” and the other, “In.” A Stacking Cable is shipped with each hub. 1-12...
  • Page 24: Optional Redundant Power Unit

    BOUT THE Optional Redundant Power Unit (RPU) An RPU can supply power to the switch in the event of a failure of the internal power supply. Contact your reseller for advice regarding the appropriate SMC RPU for your specific application. Power Supply Receptacles There are two power receptacles on the rear panel of each hub.
  • Page 25: Features And Benefits

    BOUT THE Features and Benefits IEEE 802.3 Ethernet and 802.3u Fast Ethernet compliance ensures compatibility with standards-based hubs, network cards and switches from any vendor Dual-speed ports for easy Fast Ethernet integration and for protection of your investment in legacy LAN equipment Auto-sensing enables each port to automatically determine the speed of the attached device and channel the data to the appropriate segment...
  • Page 26 BOUT THE Desktop or rack-mountable Three-year warranty 1-15...
  • Page 27 BOUT THE 1-16...
  • Page 28: Network Planning

    HAPTER ETWORK LANNING Sample Applications ....2-2 Integrating Fast Ethernet into an Ethernet LAN 2-2 Stacking the Hubs ....2-3 Extending the Stack .
  • Page 29: Sample Applications

    Sample Applications Integrating Fast Ethernet into an Ethernet Network In the illustration below, a TigerStack II 10/100 Base Hub is used standalone to integrate Fast Ethernet into an Ethernet network. The Internal Switch Module, included in the Base Hubs, interconnects the two segments to form a single LAN with an aggregate bandwidth of 110 Mbps.
  • Page 30: Figure 2-2. Stack Of Six Hubs Supporting 144 Ports

    ETWORK LANNING Stacking the Hubs Up to six hubs may be stacked, as shown below, to create a logical hub with up to 144 ports. The stack requires only one Base Hub (or Expansion hub with an optional Extender Switch Module installed) and may include two optional Network Management Modules.
  • Page 31: Figure 2-3. Extending A Stack To Other Hubs

    LANNING Extending the Stack Since the TigerStack II 10/100 is a Class II hub, it may be cascaded to a single Fast Ethernet hub or to a dual-speed hub. It may also be cascaded to multiple Ethernet hubs as long as the SMC 5-4-3 Rule is observed (see “Connectivity Rules”...
  • Page 32: Figure 2-4. Using 10/100 Extender Modules

    ETWORK LANNING Adding Extender Modules to the stack increases both the reach and bandwidth of the network. In Figure 2-4, the same two stacks are joined by a 10BASE-T/100BASE-TX Extender Module, instead of being cascaded via front-panel ports, increasing the aggregate bandwidth.
  • Page 33: Figure 2-5. Using A 100Base-Fx Extender Module

    ETWORK LANNING The 100BASE-FX Extender Module is used for long distance connections, as shown below. Figure 2-5. Using a 100BASE-FX Extender Module...
  • Page 34: Connectivity Rules

    ETWORK LANNING Connectivity Rules An overview of the rules for both Ethernet and Fast Ethernet connectivity is provided below. 100 Mbps Fast Ethernet Collision Domain SMC 3-2 Rule for Class II Repeaters t a t s i l • • SMC 2-1 Rule for Class I Repeaters t a t s i l...
  • Page 35: 10 Mbps Ethernet Collision Domain

    ETWORK LANNING 10 Mbps Ethernet Collision Domain SMC 5-4-3 Rule t a t s i l • • , ) s • , s t a t t * . ) t s i c i f . y l Maximum Cable Length , r i ) .
  • Page 36: Installing The Stack

    HAPTER NSTALLING THE TACK Selecting a Site ......3-2 Equipment Checklist ....3-3 Hub Packing List .
  • Page 37: Selecting A Site

    NSTALLING THE TACK Selecting a Site TigerStack II 10/100 hubs can be mounted in a standard 19-inch equipment rack or on a flat surface. Be sure to follow the guidelines below when choosing a location. The site should: • be able to maintain its temperature within 0° to 50° C and its humidity within 0% to 90%, non-condensing •...
  • Page 38: Equipment Checklist

    NSTALLING THE TACK Equipment Checklist After unpacking the TigerStack II 10/100 products, check the contents of each box against the included packing list to be sure you’ve received all the components. Then, before beginning the installation, be sure you have all the necessary equipment.
  • Page 39: Mounting

    NSTALLING THE TACK Mounting A TigerStack II 10/100 unit can be mounted in a standard 19-inch equipment rack or on a desktop or shelf. Mounting instructions for each type of site follow. Before mounting the devices, be sure to install any optional modules, as follows.
  • Page 40: Figure 3-1. Attaching The Brackets

    NSTALLING THE TACK To rack-mount devices: 1. Attach the brackets to the device using the screws provided in the Bracket Mounting Kit. Figure 3-1. Attaching the Brackets 2. Mount the device in the rack, using four rack-mounting screws (not provided). Figure 3-2.
  • Page 41: Figure 3-3. Attaching The Adhesive Feet

    NSTALLING THE TACK 3. If installing a single hub only, turn to “Connecting to a Power Source” at the end of this chapter. 4. If installing multiple hubs, mount them in the rack, one below the other, in any order. 5.
  • Page 42: Stacking

    A stacking cable is included with each hub. Caution: DO-NOT stack SMC’s 10 Mbps TigerStack hubs with SMC’s TigerStack II 10/100 hubs. If you attempt to do so, the hubs will be damaged. To stack the devices: 1.
  • Page 43: Connecting To A Power Source

    NSTALLING THE TACK Connecting to a Power Source Note: It is recommended that the hubs be stacked before being connected to a power source. However, a device can be added to the top or bottom of a stack that is on and operat- ing without first powering down the stack.
  • Page 44 NSTALLING THE TACK 4. If you have purchased Redundant Power Units, connect them to the other devices and to an AC power source now, following the instructions included with the package.
  • Page 45 NSTALLING THE TACK 3-10...
  • Page 46: Making Network Connections

    HAPTER AKING ETWORK ONNECTIONS Connecting Network Devices ... . . 4-2 Twisted-Pair Devices ....4-2 Cabling Guidelines .
  • Page 47: Connecting Network Devices

    10BASE-T/100BASE-TX hubs and switches, on the other hand, may have either crossover or straight-through ports. For this reason, ports 12 or 24 on the TigerStack II 10/100 hubs are not labeled with an “x”—these are switch-selectable crossover ports. The associated Crossover switches (see Figure 4-1) are used to enable and disable the wiring crossover on these ports.
  • Page 48: Figure 4-2. Making Twisted-Pair Connections

    AKING ETWORK ONNECTIONS ..Figure 4-1. Crossover Switch on the 24-Port Hub Connecting to PCs, Servers, Hubs and Switches 1. Attach one end of a twisted-pair cable segment to the device’s RJ-45 connector. Figure 4-2.
  • Page 49: Wiring Closet Connections

    ETWORK ONNECTIONS 2. If the device is a network card and the TigerStack II 10/100 is in the wiring closet, attach the other end of the cable segment to a modular wall outlet that is connected to the wiring closet (see “Wiring Closet Connections”...
  • Page 50: 100Base-Fx Devices

    AKING ETWORK ONNECTIONS Figure 4-3. Wiring Closet Connections 100BASE-FX Devices If a slide-in 100BASE-FX module is present, its fiber port may be used for backbone and longer distance connections. Each 100BASE-FX device requires 62.5/125 or 50/125 micron multimode fiber optic cabling with an SC or ST connector at both ends.
  • Page 51: 10Base2 And Aui Connections

    AKING ETWORK ONNECTIONS 10BASE2 and AUI Connections If the slide-in BNC/AUI Extender Switch Module is present, then there are options for connecting to legacy 10 Mbps segments. The toggle switch on the module’s front panel selects either the BNC or AUI port. The BNC connector provides a connection to 10BASE2 thin coax.
  • Page 52: Troubleshooting

    PPENDIX ROUBLESHOOTING Troubleshooting LED Indicators ... A-2 Power and Cooling Problems ... . . A-3...
  • Page 53: Troubleshooting Led Indicators

    ROUBLESHOOTING Troubleshooting LED Indicators • l l a . t e • t e l • e l l . l e • . t r • e l i v i t y t i • a t t •...
  • Page 54: Power And Cooling Problems

    ROUBLESHOOTING Power and Cooling Problems If the Power LED does not turn on when the power cord is plugged in, you may have a problem with the power outlet or power cord as explained in the troubleshooting chart. However, if the unit powers off after running for a while, check for loose power connections, power losses or surges at the power outlet, and verify that the fans on the side of the unit are unobstructed...
  • Page 55 ROUBLESHOOTING...
  • Page 56 PPENDIX ABLES Specifications ......B-2 Twisted-Pair Cable and Pin Assignments ..B-3 100BASE-TX/10BASE-T Pin Assignments .
  • Page 57: Cables

    ABLES Specifications , e l s r i f i t , e l s r i i t l...
  • Page 58: Twisted-Pair Cable And Pin Assignments

    ABLES Twisted-Pair Cable and Pin Assignments Caution: DO-NOT plug a phone jack connector into any RJ-45 port. Use only twisted-pair cables with RJ-45 connectors that conform with FCC standards. For 100BASE-TX/10BASE-T connections, a twisted-pair cable must have two pairs of wires. Each wire pair is identified by two different colors.
  • Page 59 ABLES 100BASE-TX/10BASE-T Pin Assignments With 100BASE-TX/10BASE-T cable, pins 1 and 2 are used for transmitting data, and pins 3 and 6 for receiving data. * The “+” and “-” signs are used to represent the polarity of the wires that make up each wire pair. Straight-Through 100BASE-TX/10BASE-T Wiring If the twisted-pair cable is to join two ports and only one of the ports has an internal crossover, the two pairs of wires must be...
  • Page 60 ABLES Crossover 100BASE-TX/10BASE-T Wiring If the twisted-pair cable is to join two ports and either both ports are labeled with an “x” or neither port is labeled with an “x,” a crossover must be implemented in the wiring.
  • Page 61 ABLES...
  • Page 62 24-Port TigerStack II 10/100 Hubs ..C-2 All TigerStack II 10/100 Hubs ... . . C-3 Slide-In Modules ..... . C-5 Internal Switch Module and All Extender Switch Modules .
  • Page 63: Specifications

    PECIFICATIONS 12-Port TigerStack II 10/100 Hubs SMC5912, or SMC5912DS Ports 12 10BASE-T or 100BASE-TX Interface RJ-45 connectors, fixed crossover Port 12 on hub only: switch-selectable crossover Segments/Unit Two, 10 Mbps and 100 Mbps Weight 9.92 lb. (4.5 kg) 24-Port TigerStack II 10/100 Hubs...
  • Page 64: All Tigerstack Ii 10/100 Hubs

    PECIFICATIONS All TigerStack II 10/100 Hubs Type Class Network Interface 100BASE-TX: Category 5 UTP, 2 pairs 10BASE-T: Categories 3, 4, 5 UTP, 2 pairs Size 17.32 x 7.87 x 2.48 in. (44.0 x 20.0 x 6.3 cm) LEDs Power Switch...
  • Page 65 PECIFICATIONS Power Consumption 50 Watts maximum Heat Dissipation 170.5 BTU/hr maximum Maximum Current 0.36A @ 110 VAC 0.22A @ 240 VAC Standards IEEE 802.3 Ethernet, 802.3u Fast Ethernet ISO/IEC 8802-3 Compliances CE Mark Safety UL 1950 CSA 22.2.950 EN60950 (TÜV) Emissions FCC Class A EN55022 (CISPR 22) Class A...
  • Page 66: Slide-In Modules

    PECIFICATIONS Slide-In Modules Internal Switch Module and All Extender Switch Modules Models SMC5900T/SW, SMC5900FSC/SW, SMC5900FST/SW, SMC5900BA/SW Network Bridging Function Filtering, forwarding and learning Switch Method Store-and-forward Address Table 4K entries Queue Buffer 1 Mbyte shared memory Address Resolution Via fast hashing scheme Filtering Rate 14,880 pps at 10 Mbps, 148,800 pps at 100 Mbps Forwarding Rate...
  • Page 67: 100Base-Fx Extender Modules

    PECIFICATIONS LEDs Link Activity Collision Full/Half 100M Toggle Switch 100 Mbps full duplex/Auto-Negotiation Standards IEEE 802.3 Ethernet, 802.3u Fast Ethernet ISO/IEC 8802-3 100BASE-FX Extender Modules Models SMC5900FSC, SMC5900FST, SMC5900FSC/SW, SMC5900FST/SW Ports 1 100BASE-FX Network Interface SC or ST connector, 62.5/125 or 50/125 micron multimode fiber cable LEDs Link...
  • Page 68: Bnc/Aui Extender Module

    PECIFICATIONS BNC/AUI Extender Module Model SMC5900BA/SW Ports 1 10BASE2 BNC or AUI 15-pin D-type connector (switch selectable) Network Interface 10BASE2: Thin coax, RG-58A/U or RG-58C/U AUI: External transceiver drop LEDs Activity Collision Toggle Switch BNC/AUI Standards IEEE 802.3 Ethernet ISO/IEC 8802-3 Network Management Module Model SMC5900NMM...
  • Page 69 PECIFICATIONS SNMP Support MIB II (RFC 1213), Multi-Segment Repeater MIB (RFC 2108), Ethernet-Like MIB (RFC 1643), RMON MIB (RFC 1757), SMC’s private MIB RMON Support Groups 1, 2, 3, 9 (Statistics, History, Alarm, Event)
  • Page 70: Ordering Information

    PPENDIX RDERING NFORMATION TigerStack II 10/100 Products & Accessories . . D-2...
  • Page 71 RDERING NFORMATION e t i * Also available in models for Continental Europe and the UK.
  • Page 72: Glossary

    PPENDIX LOSSARY Glossary of Terms ....E-2...
  • Page 73: Glossary Of Terms

    LOSSARY Glossary of Terms 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3, 4, or 5 UTP cable. 100BASE-FX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two strands of 62.5/125 or 50/125 micron core fiber cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 UTP cable.
  • Page 74 LOSSARY Class I Repeater Fast Ethernet repeater that is principally used to connect different physical signaling systems (e.g., 100BASE-TX, 100BASE-FX) and that has an internal delay such that only one repeater of this type can reside within a single collision domain when maximum cable lengths are used.
  • Page 75 LOSSARY LAN Segment Separate LAN or collision domain. Link Segment Length of twisted-pair or fiber cable joining a pair of repeaters or a repeater and a PC. Network Diameter Wire distance between two end stations in the same collision domain. Out-of-Band Management Management of the network from a station that is not attached to the network.
  • Page 76 LOSSARY Switched Ports Ports that are on separate collision domains or LAN segments. Unshielded twisted-pair cable.
  • Page 77 FOR TECHNICAL SUPPORT, CALL: From U.S.A. and Canada (8:30 AM - 8:00 PM Pacific Time) (800) SMC-4-YOU; (949) 707-2400; (949) 707-2460 (Fax) From Europe (8:00 AM - 5:30 PM UK Greenwich Mean Time) 44 (0) 1344 420068; 44 (0) 1344 418835 (Fax) INTERNET E-mail addresses: techsupport@smc.com...
