CONFIGURATION AND MANAGEMENT

Downloading System Software

System software updates can be downloaded either in-band via
TFTP Protocol or out-of-band through the console port.
Downloading software via TFTP is substantially faster than serial
downloading through the console port. After either type of file
transfer, the switch will automatically restart.

Downloading via TFTP Protocol

In order to use this method, there must be an available TFTP
server which is IP accessible from the switch.
TFTP Server Address
Download Filename
Execute Network Download
Return to Previous Menu
Use cursor keys to choose item.
Press <CTRL><N> to return to the Main Menu.
Figure 4-14. TFTP Download Screen
1. Highlight "TFTP Download" in the Main Menu and press
<ENTER>. This will access the TFTP Download Screen.
2. Highlight "TFTP Server Address" and press <ENTER> to
input an IP address for the TFTP server. Press <ENTER> to
confirm entry.
3. Highlight "Download Filename" and press <ENTER> to
input the file to be downloaded, if required. The file should
be a *.bin file from SMC. Press <ENTER> to confirm entry.
4-28
TFTP Download
210.68.150.232
XXXXXXXX.bin
Press <ENTER> to confirm choice.
