Optional Redundant Power Unit

SMC's Redundant Power Units (RPUs) are separate devices and
each has its own power cord. These devices can supply power
to the unit in the event of a failure of the internal power supply.
The available RPUs are listed in the table below. Contact your
reseller for advice regarding the appropriate RPU for your
specific application.
Order Number
SMC-RPUX1
SMC-RPUX5

Power Supply Receptacles

There are two power receptacles on the rear-panel of each
TigerSwitch 100. The standard receptacle labeled "Power" is for
the AC power cord. The 14-pin receptacle labeled "DC Input" is
for the optional Redundant Power Unit (RPU).
Figure 1-10. Power Supply Receptacles
Redundant Power Units (RPUs)
Supports one SMC device
Supports up to 5 SMC devices
A T
BOUT THE IGER
Description
S 100
WITCH
1-9
