CONFIGURATION AND MANAGEMENT

Port Configuration

1. Highlight "Port Configuration" in the Main Menu and press
<ENTER>. This will access the Port Configuration Screen
illustrated below.
Port Enabled
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
Return to Previous Menu
Selecting Half or Full Duplex?
Use cursor keys to choose item.
Press <CTRL><N> to return to the Main Menu
Figure 4-6. Port Configuration Screen
2. Highlight the setting under the "Enabled" column for the
chosen port and press <ENTER> to use the arrow keys to
toggle between enabling and disabling the port. Press
<ENTER> again to confirm the choice.
3. Highlight the setting under the "Duplex" column to adjust
the communication mode for the chosen port. Press
<ENTER> to use the arrow keys to cycle through Full-
duplex, Half-duplex or Auto-Negotiation modes.* Press
<ENTER> again to confirm the choice.
4. Highlight the setting under the "AgingTime" column to
adjust Address Aging for the chosen port. Address Aging is
the amount of time addresses will remain in the address
table before being deleted. Press <ENTER> to input a value
between 0 and 43200 seconds. Press <ENTER> again to
confirm the chosen value.
4-14
Port Configuration
Duplex AgingTime
Auto 300
Auto 300
Auto 300
Auto 300
Half 300
300
Auto 300
Auto 300
SwitchingMode
CT
CT
CT
CT
CT
CT
CT
CT
Press <ENTER> to confirm choice.
FlowControl
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
