Diagnostic Tests

Upon power-up, the TigerSwitch 100 units perform self-
diagnostic tests (See Chapter 3). Diagnostic tests similar to
those performed on power-up can be run using the Configure
button:
1. Use a long press (>2 seconds) to begin function selection.
The Status LED will start to flash to indicate that functions
may be selected. Use short presses (<2 seconds) to cycle
through the status LEDs until the Diagnostic LED lights. Use
a long press to initiate diagnostic tests.

System Diagnostic Tests

The diagnostic test sequence is performed in two stages. The
first stage is the system diagnostic test. The following table
details system level failures, which are indicated in the
Select/Link row of the LED array:
Component Failure
System ROM
System RAM
System EEPROM
System Failures
LED Array Indicator Column
T
ROUBLESHOOTING
1
2
3
A-3
