1.3 Product Package
Upon delivery, open the package and remove all packaging materials.
Check to ensure there is no visible damage to the products. If damage is detected, notify the
carrier immediately.
After unpacking, check the part number label on the product. Make sure it matches the
product your ordered, and that the voltage meets your specific requirements.
The CD3E package includes the following items:
CD3E servo drive
⚫
Power mating connector
⚫
STO bypass plug
⚫
1.4 Product Label
Table 1-1. CD3E Product Label Codes
Item Description
Model Catalog number (ordering information)
S/N Product serial number.
Digits 1–14 = Material code
Digits 15–20 = Production year, month and day
Digit 21 = Production workshop
Digit 22 = Production type
Digits 23-27 – Production serial number
HW Hardware version
Figure 1-1. CD3E Product Label – Example
