CD3E
Feature
3.9 Motor Feedback Specifications
Table 3-8. Motor Feedback Specification
Feature
Supply voltage from drive
Max. supply current from drive
Recommended cable type
Encoder type
Quick Start Guide
错误!使用"开始"选项卡将 Heading 1 应用于要在此处显示的文字。
Specification
Signal format
Voltage level
Maximum output
current
Short-circuit protection
Transmission delay time 1 µs
Specification
5.2 VDC
Shielded twisted-pair copper wire
BiSS-C, AB incremental
Opto-isolated. NPN (sinking)
5 to 24 V
50 mA
Yes
15
