DiGidot C4 Manual page 53

Dictionary
SPI
IC
IC/SPI protocol
Scene
Playlist
Actionlist
Universe
I/O configuration
Compliances & EU declaration of Conformity
This product is designed and produced by DiGidot BV, Amsterdam, The Netherlands.
Hereby, DiGidot BV declares that the DiGidot C4 device complies with and was tested
according to essential requirements of all relevant CE directives.
Certificate of CE conformity: No. 2016/119-1
cETL US Listed - Intertek 5010008 I.T.E.
Conforms to ANSI/ UL 62368-1
Cert. to CAN/CSA C22.2#62368-1
DiGidot is a registered DMX-RDM manufacturer at http://tsp.esta.org, under ID 00B6h.
DiGidot registered Art-Net manufacturer at https://artisticlicence.com, under ID 0x0fd0.
C4 Manual
G d ot
Serial Peripheral Interface; This is an interface bus between that is
used to send data between microcontrollers and IC's.
Integrated Circuit; this is an electronic component which houses a
ready made circuit that is able to perform one specific task. An IC
can be placed separately on a PCB or integrated in a LED package
to control/drive a LED or segment/array of LEDs.
Type of control protocol that is used by an IC.
A scene can also be referred to as a cue and can contact static and
dynamic values that control specific channels.
A playlist consists of multiple scenes that are played in a specific
order according to pre programmes parameters.
Typically a universe is referred to as one DMX control network
consisting of 512 control channels, also typically associated with
one DMX output. DiGidot also refers to a universe as one set of 512
control Channels that belong to specific Art-Net or DMX universes.
But when we mention more than one universes on one output for
example, we always refer to them as amount of control channels
and not necessarily as DMX universes.
Input/Output configuration, determines how and which signals the
C4 is controlled by and how the ports of the C4 are configured.
Version 1.0 53
