Select a segment type from the dropdown menu.
Segment type
No segments - Disables segments (Default)
Create segments - Allows to create your own segmentation
RGB(W) LED segments - Link multiple LEDs together (e.g.: channel 1&4&7,
2&5&8, ...)
Single color segments - Groups channels together (e.g.: channel 1-3, 4-6, ...)
Gamma correction
Gamma correction adjust the overall brightness of the output. This option is used if
you want to display real looking videos instead of high saturated effects.
Color profile
Rearrange the LED color order, for example from RGB to BGR. You can select a few
standard conversion profiles or create your own Custom profile. This might be re-
quired for some LED products. The DiGidot C4 uses the default color order from the
technical documentation of a selected IC/SPI protocol.
Fallback color
This function allows to select a color that will be send to all output channels as
soon as no Art-Net signal is detected.
Color
Enter a RGB value between 0 and 255 per LED channel or use the color
picker to select a color easily. If you use the color picker, you can also adjust
the saturation and brightness by adjusting the sliders underneath. After
selecting the fallback color, hit the
to confirm your selection.
Timeout
Enter a delay/timeout in ms (milliseconds) when the fallback color becomes
active after signal loss.
Advanced input
Further universe specific settings can be changed;
Only accept Art-Net from IP address: enter a dedicated IP address that this
universe listens to.
Analog dimming: select one of the three analog inputs that will control the
overall brightness of this IO configuration item.
Max time until resend: This option allows to adjust the timing of data pack
ages that are being sent to the ICs. Some ICs might show hiccups when they
cannot process the speed of data that is being sent from the DiGidot C4. This
value also indirectly affects the frame rate (fps) . The default value is defined
by IC type. Reset this value to it's default by pressing delete > generate a new
universe again by selecting the blue + button of the specific D port.
When you are finished adjusting the advanced options, click 'save' to store the set-
tings.
