DiGidot TRxB
Art. no.: 20327
Operating voltage: 5-48 Vdc
Converts one balanced SPI signal to one unbalanced SPI output.
Can directly be soldered to the beginning of a SPI controlled LED strip
RJ45 bus and solder pads for signal input
Optional screw terminal for output (upon request)
Accessories
DiGidot TRRS Trigger Cable
Art. no.: 20903
Optional cable to connect 3 analogue trigger inputs of C4 Extended.
1 meter in length.
DiGidot RJ45 Network Cable
Art. no.: 20330
RJ45 Network cable for connecting and daisy chaining DiGidot C4
(included with DiGidot C4 Extended)
DiGidot USB Power Cable
Art. no.: 20331
Power cable to connect DiGidot C4 to 5 Vdc USB port
(included with DiGidot C4 Extended)
DiGidot DIN-rail Clip
Art. no.: 20902
Optional DIN-rail Mounting Clip for DiGidot C4
DiGidot 8GB microSD Card
Art. no.: 20901
Industrial grade spare micro SD memory card for DiGidot C4 Extended
(included with DiGidot C4 Extended)
For further DiGidot products, Transceiver kits and accessories visit our website www.
digidot.eu.
Online resources
For technical specifications, latest documentation, manuals, product information, sup-
port and upgrades, please visit www.digidot.eu.
Remarks
We've put great care in writing this manual. However in case you encounter any dis-
crepancies or unclarities, please contact us. This manual and function specific instruc-
tions are based on firmware and interface versions mentioned in the chapter 'Manual
version'.
NOTE: Please note that this manual covers information for the DiGidot C4 Live and
Extended controllers. In case of C4 Live controllers, some of the features may not be
displayed in the user interface because they are limited to the Extended version only (refer
to appropriate symbols in this manual).
