ADDITIONAL INFORMATION
8
Accessories
DiGidot offers various accessories for your installation. Please contact your DiGidot
reseller to order other following DiGidot products.
Transmitting modules
DiGidot Tx
Art. no.: 20303
Operating voltage: 12-24 Vdc
Converts four DMX TTL signals to four balanced DMX outputs
Converts one to four unbalanced SPI signals to one to four balanced SPI signals
to transmit over large distance up to 250 meters
DiGidot TxRJ PCB
Art. no.: 20305
Operating voltage: 12-24 Vdc
Converts one to four DMX TTL inputs to one to four balanced DMX outputs
Converts one to four SPI inputs to one to four balanced SPI outputs to transmit
over large distance up to 250 meters
Four RJ45 output ports
DiGidot TRDM PCB
Art. no.: 20306
Operating voltage: 5-60 Vdc
DMX RDM capable for configuring DiGidot CRX modules
Converts one to four DMX TTL inputs to one to four balanced DMX outputs
Converts one to four SPI inputs to one to four balanced SPI outputs to transmit
over large distance up to 250 meters
Four RJ45 output ports
Receiving modules
DiGidot Rx24
Art. no.: 20321
Operating voltage: 12-24 Vdc
Converts one balanced SPI signal to one unbalanced SPI output.
Can directly be soldered to the beginning of a SPI controlled LED strip
DiGidot Rx48
Art. no.: 20326
Operating voltage: 12-48 Vdc
Converts one balanced SPI signal to one unbalanced SPI output.
Can directly be soldered to the beginning of a SPI controlled LED strip
RJ45 bus and solder pads for signal input
