Limit outputs
On this page you can set the master brightness, the brightness limiter and the adaptive
power limiter.
Brightness limiter
This option limits the individual channels to a specific percentage. This means that
every channel or LED will never exceed this percentage.
E.g.: Limiting brightness to 50%, means that all individual channels can never exceed
50% but the control range per channel will remain the same. Effectively the percent
age is applied to the input value for each channel.
Adaptive power limiter
This option limits the total average output of all channels combined to a specific
percentage in order to decrease total power consumption. Individual channels my still
output up to 100%.
E.g.: Limiting power to 50% means that half of the channels can output 100% and the
other half at 0% or all channels at 50%, etc.
In case you would try to output all channels to 75%, the output of all channels
would be automatically limited to a total 50%, but will maintain ratios relative to
each other.
Delete configuration
Deletes all IO configuration settings of selected devices.
I/O detail page
Open the user interface
Channels/Pixel segments: Define the number of output channels or number of pixel
segments.
Universe: assign an universe number as input.
Further configuration options will be shown when you activate the Show advanced set-
tings option.
Advanced IO config
Start-channel offset
This option allows you to enter an offset value of the starting channel that this universe
listens to. By entering a start channel (0-511), all channel data before this channel off-
set will be skipped.
Example
Goal: You want to use channels 100 up to channel 200 as output channel 0-100.
Configuration settings will be as follows:
Start channel is set to 100.
Channels is set to 200.
Explained: First, the start channel will shift 100 channels of the input. This will skip the
first 100 channels of the universe. Then set the channels to 200, because 200 channels
are required, starting after the first 100 skipped channels.
Create segments
This option allows to combine multiple channels or LEDs in order to become one pixel/
segment. It's recommended to use this option only if the amount of control channels
needs to be reduced.
