Analog triggers
Home Triggers
The Digidot C4 features three analog inputs that can be used to control various func-
tions. There are four different ways to use the analog inputs:
Push button or switch
0-10V dimmer*
0-10V control signal from an external control system*
Potentiometer (50 Lin)*
*(not fully supported yet, only for master brightness)
Please make sure that the analog inputs are connected correctly before you start using
them (see page XX).
If this..
This menu shows the available input options.
Analog channel: Select the analog channel 1-3 that you want to use for
triggering.
Active trigger: Define the trigger event/state and optional the delay or
duration of the event.
Then..
This menu shows the available events that can be configured.
Select the devices that you want to trigger by this action.
Select the action type and action parameters, if applicable.
When you've finished your trigger setup, click SAVE to store your trigger settings.
Art-Net and DMX triggers
Home Triggers
You can use Art-Net and/or DMX to trigger various actions.
Art-Net triggers (default)
If this..
Input universe: Select the input universe of the incoming signal.
Channel: Select the channel that is used for this trigger.
Minimum: Define the minimum channel value (0-254)
Maximum: Define the maximum channel value (1-255).
Then..
This menu shows the available trigger actions that can be configured.
Select the devices that you want to trigger by this action.
Select the action type and action parameters, if applicable.
DMX triggers
How to configure ports as DMX in?
You can configure the ports D1-D4 to one or two DMX inputs.
In case that port D1 & D2 and/or D3 & D4 are available (if no SPI protocol has been
configured for these ports), you can choose which ports you want to configure as DMX
input. If all ports are already in use you have to re-configure the input/output configu-
ration (see page XX) or you can go Settings > In/Out configuration and adjust I/O setting
per port.
Please note that DMX uses two ports for data DMX + and DMX -.
