Settings overview
Kleine uitleg!!
Inputs & outputs configuration (manual configuration)
Open the user interface
On this page you can manually configure the inputs and outputs. Choose the output
type (or DMX input) for these ports. Then click the blue + icon of each port to generate
an universe. To edit the output options, click the universe item.
The DiGidot C4 is able to output one SPI protocol type simultaneously. If you select a
SPI protocol for one port, this protocol will be used for all other output ports.
You can however make a combination with 'DMX input' or 'DMX output'.
Combining ports example:
Port D1 is set to DMX out and will automatically be combined with port D2, because 2
data lines for a (balanced) DMX signal are required. You can now select a protocol for
D3+D4.
Note that a DiGidot C4 starts to count universes at 0 (zero)! Some softwares or con-
soles may start counting at universe 1.
Additional tools
In the right top menu you will find additional tools.
LED configuration wizard
This wizard guides through a few simple steps to select the IC protocol and and defines
which channels are used to control the outputs. In order to help you to define the right
amount of control channels, you can use the 'calculate output' tool in step 2.
If you have used the Getting started wizard, you don't need to go through this wizard,
unless you want to change the output/LED configuration again.
Autocomplete configuration
Use this tool to copy the configuration of the first port of the first device to a the se-
lected ports/devices. The interface will show various autocomplete options, depending
on your system setup.
Global configuration
This page offers advanced configuration item options that apply to all selected devices.
Such as;
Gamma Correction
Color profile
Fallback options
IP Address filter
Input watcher
The input watcher is a useful tool that monitors incoming control signals. You can
switch between:
Art-Net: you can select a specific universe that you want to monitor
DMX: switch between the inputs if you have configured one or more ports as
DMX In.
