DiGidot C4 Manual page 34

If this..
Select DMX port: Select the DMX port where the trigger signal is coming
from.
Channel: Select the channel that is used for this trigger.
Minimum: Define the minimum channel value (0-254)
Maximum: Define the maximum channel value (1-255).
Then..
This menu shows the available trigger actions that can be configured.
Select the devices that you want to trigger by this action.
Select the action type and action parameters, if applicable.
On board button
Home Triggers
The on board button of the DiGidot C4 can be programmed to trigger various actions.
This feature is very useful for mobile applications and demonstration setups.
If this..
Button event: Select the preferred button event.
Delay/duration (optional): Add a delay or duration in milliseconds to a
button event.
Then..
This menu shows the available trigger actions that can be configured.
Select the devices that you want to trigger by this action.
Select the action type and action parameters, if applicable.
Time/date
Home Triggers
The DiGidot C4 has a build-in clock to trigger various time based actions.
Every time the interface loads, the browser/app time will be used to synchronise the
DiGidot C4 time and date. Once the time and date are set, the on-board battery will
keep the internal clock running.
If this..
Repeat: Enable to create a repeating trigger, otherwise it triggers only
once.
Every: Repeating frequency of this trigger, e.g. every 'day' or every 'week'
etc.
Date and time fields: Define a date and time (multiple inputs possible
depending on chosen frequency).
Then..
This menu shows the available trigger actions that can be configured.
Select the devices that you want to trigger by this action.
Select the action type and action parameters, if applicable.
UDP/HTTP-Get
Home Triggers
You can send specific commands from external systems and devices to trigger various
actions. These digital triggers are very useful for system integration and automation.
This also allows other developers to incorporate control over the DiGidot C4 in other
software programs.
If you need further API information, please contact us.
C4 Manual
G d ot
select '+' to add a trigger
select '+' to add a trigger
select 'How to use HTTP and UDP triggers'
Version 1.0
select 'Button'
select 'Time/date'
