Dot-line
on printhead
EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
Length
Origin
X-start Width (1-1322)
Dot #0
Print Window 11.81 dots/mm (300 dpi) printhead

Media Type

The Media Type parameters control how the label stop sensor
(LSS) and the media feed work. There are five media type
options:
• Gap is used for adhesive labels mounted on liner (backing
paper) or continuous paper stock with detection slots.
Default.
• Mark is used for labels, tickets, or strip provided with black
marks at the back.
• Continuous is used for continuous stock without any
detection slots or black marks.
• Label (with gaps) is used for adhesive labels mounted on liner.
• Ticket (with mark) is used for labels, tickets, or continuous
stock provided with black marks at the back.
Chapter 6 — Setting Up the Printer
max. 112 mm (4.4 in)
PRINT PRINT PRINT
WINDOW WINDOW WINDOW
FEED
DIRECTION
25-120 mm (1-4.7 in)
8 mm (0.32 in)
Dot #1321
69
