Appendix C — Interfaces
158
EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
Double Serial Interface Board
Serial/Industrial Interface Board
IEEE 1284 Parallel Interface Board
"uart3:"
RS-232,
RS-422 non isolated,
or 20 mA current loop
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
+
Industrial interface
8 digital In ports
8 digital Out ports
4 relay ports
"uart2:"
RS-232,
RS-422 non isolated,
RS-422 Isolated,
or RS-485
"centronics:"
