Appendix A — Technical Data
138 EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
Printing
Print Technique
Printhead Resolution
Print Speed (variable)
Print Width (max)
Print Length (max)
Media Width
(min/max)
Media Roll Diameter
(max)
Media Roll Core
Diameter
Ribbon Width
(min/max)
Ribbon Roll Diameter
(outer), max.
Print Technique
Ribbon Roll Core
Diameter (inner)
Print Directions
Note 1: The maximum print length is also restricted by the amount of
free SDRAM memory.
Modes of Operation
Tear-Off (Straight-through)
Cut-Off
Peel-Off (Self-strip)
Internal Batch Takeup
Direct Thermal and Thermal Transfer
8 dots/mm (203.2 dpi)
11.81 dots/mm (300 dpi)
100 to 300 mm/sec (± 4 to 12 in/sec)
112 mm (4.41 in) - Direct Transfer
110 mm (4.33 in) - Thermal Transfer
32767 dots
= 409.5 cm (161.25 in) at 203.2 dpi
=277.5 cm (109.23 in) at 300 dpi
See Note 1
25 to 120 mm (1 to 4.72 in.)
213 mm (8.38 in) Tear-Off
205 mm (8.07 in Peel-Off
38 to 40 mm (1.5 in)
76 mm (3 in) with adapter fitted
55 to 110 mm (2.17 to 4.33 in)
80 mm (3.15 in)
± 450 m (1476 ft) of ribbon
Direct Thermal and Thermal Transfer
25 mm (1 in)
4
Yes
Option
Option
Option
With cutter
With rewinder
With rewinder
