Chapter 6 — Setting Up the Printer
68 EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
(LSS) has not detected a gap or mark within 150% of the set
length, the media feed is automatically stopped to avoid
feeding out a whole roll of media, because of an LSS
malfunction.
By setting up the X-Start, the Width, and the Length, you will
create a print window inside which the printing can be
performed. Any object or field extending outside the print
window in any direction will either be clipped or cause an error
condition (Error 1003 "Field out of label"), see Intermec
Fingerprint v8.xx, Command Reference Manual.
Length
Origin
Dot-line
on printhead
X-start Width (1-896)
Dot #0
Print Window 8 dots/mm (203.2 dpi) printhead
max. 112 mm (4.4 in)
PRINT PRINT PRINT
WINDOW WINDOW WINDOW
FEED
DIRECTION
25-120 mm (1-4.7 in)
8 mm (0.32 in)
Dot #895
