Display

Keyboard

EasyCoder PX4i Bar Code Label Printer User's Guide (Fingerprint Version)
Status (flashing green) indicates that the printer is
communicating.
Status (solid red) indicates an error condition (see
"Troubleshooting" on page
Intermec Ready-to-Work indicator (blue; on, blink, or off ). The
indicator has three different states: On, Blinking, and Off. When
the indicator is On, the printer is ready for use. When the
indicator is blinking, the printer may be initializing, waiting for
external resources, or in need of user attention. When the
indicator is off, the printer is not ready to operate.
The display window contains an LCD (Liquid Crystal Display)
with background illumination and two lines of text, each with 16
characters. It provides information on installed firmware or
running application, prompts the operator in Intermec Shell and
in the Setup Mode, and can show information on possible errors
and active communication channels. The Intermec Fingerprint
programming language and the Intermec Direct Protocol allow
custom-made messages to be composed and displayed according
to the requirements of the application.
The keyboard is of the membrane-switch type and has 22 keys.
The keyboard is supplemented by a large Print button. Some
keys have hard-coded functions in the startup and setup modes.
Keyboard Buttons
Button
Print button
Chapter 2 — Installation
107).
Function
Feeds a page or pauses a print job. Repeats last
printed label.
Toggle between pause and printing when
executing a print job.
13
