Summit Switch Installation
Figure 35: Fitting the mounting bracket into the Summit48si switch
7 Repeat steps 4 through 6 for the other side of the switch.
8 Insert the switch into the rack, and ensure that ventilation holes are not obstructed.
If you are installing a Summit7i switch, you need a minimum of two people to help lift and place the
switch on the helper bracket, and slowly guide the switch into the rack.
9 While holding the switch, secure it with suitable screws (not provided).
If you are installing a Summit7i switch, remove the helper bracket after you secure the chassis.
10 Connect the Summit switch to a redundant power supply (if applicable).
11 To turn on power to the system, connect the AC power cable(s) to the switch and then to the wall
outlet(s).
NOTE
The Summit1i, Summit5i, Summit7i, Summit48i, and the Summit48si switches do not have on/off
switches.
90
Alternate
long bracket
Extreme Networks Consolidated "i" Series Hardware Installation Guide
48si_rack
