NOTE
If congestion is detected on a port with flow control enabled, a flow control PAUSE frame is sent out
that port. The PAUSE frame is not sent out on the other port in the group.
Table 72 describes the media types and the associated maximum distances for the GM-16X
Table 72: G16X
Mini-GBIC Type
1000BASE-SX
1000BASE-LX
1000BASE-ZX
Mini-GBIC Ports
3
The G16X module supports any of the following mini-GBICS:
• SX mini-GBIC
• LX mini-GBIC
• ZX mini-GBIC
NOTE
For more information about the supported mini-GBIC types, see "Mini-GBIC Types and Specifications"
on page 18.
LEDs
3
The G16X module has the following LEDs:
• Module status
• Port status
• Diagnostics
For information about the LEDs and their activity on the G16X
page 267.
Software Requirements
The G16X 3 module requires that you load ExtremeWare version 7.0.1b11 or later and BootROM 7.8 or
later on the switch.
Hardware Requirements
The G16X 3 requires a BlackDiamond chassis using MSM switch fabric module(s).
Extreme Networks Consolidated "i" Series Hardware Installation Guide
3 media types and distances
Media Type
multimode fiber
single-mode fiber
single-mode fiber
Maximum Distance
(meters)
550
10,000
70,000
3
module, see "I/O Module LEDs" on
Configuring I/O Modules
3
module.
