Chapter 17 Blackdiamond 6800 Series Switch Fan Tray; Blackdiamond 6816 Fan Trays - Extreme Networks Summit Summit1i Hardware Installation Manual

17
BlackDiamond 6800 Series Switch
Fan Tray
This chapter describes:
• BlackDiamond 6816 Fan Trays on page 273
• BlackDiamond 6808 Fan Tray on page 274
• BlackDiamond 6804 Fan Tray on page 275
• Removing a BlackDiamond 6800 Series Fan Tray on page 276
• Installing a BlackDiamond 6800 Series Fan Tray on page 278
NOTE
Read the information in this chapter thoroughly before you attempt to install or remove any
BlackDiamond fan tray.

BlackDiamond 6816 Fan Trays

The BlackDiamond 6816 fan trays (no. 53013):
• Contain nine individual fans
• Are preinstalled at the factory
• Are accessed from the front of the chassis
• Are hot-swappable which means you can remove and replace a fan tray without powering down the
system
CAUTION
Do not cover or obstruct the fan ventilation holes at the side of the unit. Doing so can result in
overheating and possible damage to the BlackDiamond 6816 switch. Thermal sensors will shut down
the BlackDiamond 6816 switch if the internal temperature exceeds 60 degrees Celsius.
ExtremeWare monitors the fan trays in the BlackDiamond 6816 switch for failure and overheat
conditions. All fan failures and over temperature events cause the switch to send alerts to the network
management station or to the switch log. See the ExtremeWare Software User Guide for more information
on switch monitoring.
Extreme Networks Consolidated "i" Series Hardware Installation Guide 273
