Table 32: Port configurations available on Alpine I/O modules (continued)
Ethernet Ports
Module
FM-24MFi
FM-8Vi
WM-4T1i
WM-4E1i
WM-1T3i
1 The GM-4Xi supports 1000BASE-SX, 1000BASE-LX, and 1000BASE-LX70.
3
3 The GM-16X
4 The GM-16T 3
5 The FM-8Vi has eight internal loopback ports for rate shaping. Module supports 10BASE-S.

Switch Components

There are three models in the Alpine 3800 series: the Alpine 3808 switch, the Alpine 3804 switch, and
the Alpine 3802 switch. This section describes the three Alpine models.

Alpine 3808 Switch

The Alpine 3808 switch consists of the following components:
• One 9-slot chassis with backplane
• Eight I/O module slots, labeled 1 through 8
• One SMMi slot
• One or two power supplies (accessed from the front of the unit)
• One fan tray (accessed from the front of the unit)
• One electromagnetic discharge (ESD) wrist strap connector

Alpine 3804 Switch

The Alpine 3804 switch consists of the following components:
• One 5-slot chassis with backplane
• Four I/O module slots, labeled slots 1 through 4
• One SMMi slot
• One or two power supplies (accessed from the rear of the unit)
• One fan tray
• One electromagnetic discharge (ESD) wrist strap connector

Alpine 3802 Switch

The Alpine 3802 switch consists of the following components:
Extreme Networks Consolidated "i" Series Hardware Installation Guide
10BASE-T/ 100BASE-TX/
100BASE-TX 1000BASE-T
2
2
2
supports 1000BASE-X.
supports 10/100/1000BASE-T autonegotiation.
GBIC 1000BASE-SX 100BASE-FX
24
Switch Components
OTHER
5
8 VDSL
4 T1
4 E1
1 T3
105
