Design Guide | iC2-Micro Frequency Converters

How to Order

8

Model Code

8.1
The configuration of the drive is reflected in the model code. The model code can be used to identify the specific drive configuration and
its inbuilt features.
1 2 3 4 5 6 7
i C 2 - 3 0 F
Figure 59: Model Code
Table 59: Example of a Final Model Code
Description
Product group
Product category
Product type
Mains voltage
Current rating
Protection rating
EMC category
Integrated brake chopper

Ordering Accessories and Spare Parts

8.2
Table 60: Code Numbers for Ordering Accessories
Category
IP21/Type 1 conversion kits
98 | Danfoss A/S © 2024.08
8 9 10 11 12 13 14
A 3 N 0 4 - 0
1 N 0 2
Position Function
1–6 iC2-30
7–8 FA: Frequency converter, air-cooled
9–10 • 3N: 3-phase power supply
• 1N: 1-phase power supply
11–12 • 01: 100–120 V AC
• 02: 200–240 V AC
• 04: 380–480 V AC
14–17 01A2–46A2
18–20 E20: IP20/Open Type
21–22 • F0: C1 category (with integrated EMC filter)
• F2: C2 category (with integrated EMC filter)
• F4: C4 category (without integrated EMC filter)
Plus code • +ACBC: With integrated brake chopper
• +ACXX: Without integrated brake chopper
Part name
IP21/Type 1 conversion kit, MA01c
IP21/Type 1 conversion kit, MA02c
IP21/Type 1 conversion kit, MA01a
IP21/Type 1 conversion kit, MA02a
IP21/Type 1 conversion kit, MA03a
15 16 17 18 19 20 21
1 A 2 E 2 0 F
F
F
22 23 24 25 26 27
0 + A C B C
2 A C X X
4
Code number
132G0188
132G0189
132G0190
132G0191
132G0192
AJ402315027937en-000401 / 130R1239
How to Order
